Dissolved Oxygen Sensor
Granfoo
Dissolved Oxygen Sensor
| Quantity: | |
|---|---|
Description
The DS380 series of fluorescent dissolved oxygen sensors use a new generation of fluorescence lifetime technology and high performance fluorescent materials. No oxygen consumption,No flow rate limitation, no electrolyte, no maintenance and calibration,no interference from hydrogen sulfide, excellent stability. Built-in temperature sensor, automatic temperature compensation. RS485 output, can be networked without a controller.
Features
* Digital sensor, RS485 output, support MODBUS * There is no electrolyte, no interference, no need for frequent calibration * No oxygen consumption, no flow rate limit * Built-in temperature sensor, automatic temperature compensation.
Technical parameters
Product Name | Fluorescence Dissolved Oxygen Sensor |
Measure Range | 0-20mg/L or 0 ≤ 200% saturation |
Response Time | 10sec |
Accuracy | ±5% |
Sensor Drift | <1% per year |
Temperature Range | 0~50℃ |
Temperature Accuracy | ± 0.2°C |
Output Siginal | Support RS-485, MODBUS protocol |
Temperature Sensor | NTC |
Housing Diameter | 22mm |
Housing Length | 160mm |
Cable Length | 5 meters (default), can be customized |
Power Supply | DC 6~12V, current <50mA |
IP Grade | IP68 |
Housing Material | POM /316/Titanium Alloy |
Description
The DS380 series of fluorescent dissolved oxygen sensors use a new generation of fluorescence lifetime technology and high performance fluorescent materials. No oxygen consumption,No flow rate limitation, no electrolyte, no maintenance and calibration,no interference from hydrogen sulfide, excellent stability. Built-in temperature sensor, automatic temperature compensation. RS485 output, can be networked without a controller.
Features
* Digital sensor, RS485 output, support MODBUS * There is no electrolyte, no interference, no need for frequent calibration * No oxygen consumption, no flow rate limit * Built-in temperature sensor, automatic temperature compensation.
Technical parameters
Product Name | Fluorescence Dissolved Oxygen Sensor |
Measure Range | 0-20mg/L or 0 ≤ 200% saturation |
Response Time | 10sec |
Accuracy | ±5% |
Sensor Drift | <1% per year |
Temperature Range | 0~50℃ |
Temperature Accuracy | ± 0.2°C |
Output Siginal | Support RS-485, MODBUS protocol |
Temperature Sensor | NTC |
Housing Diameter | 22mm |
Housing Length | 160mm |
Cable Length | 5 meters (default), can be customized |
Power Supply | DC 6~12V, current <50mA |
IP Grade | IP68 |
Housing Material | POM /316/Titanium Alloy |
